1998 MAZAK VTC 20C
1998 MAZAK VTC 20C
Location:Belgium
Description
Mazak 3-axis vertical machining center available for immediate delivery.
In good working condition with chip conveyor, synchrotapping and cooling through the spindle.
Viewing possible upon appointment.
FYI: second identical machine available at the same location in West-Flanders (Belgium).
Specifications
| Manufacturer | MAZAK |
| Model | VTC 20C |
| Year | 1998 |
| Condition | Used |
| Stock Number | 00074 |
| CNC Control | Mazatrol M Plus |
| Number of axes | 3 |
| X-travel | 1,660 mm |
| Y-travel | 510 mm |
| Z-travel | 510 mm |
| Table dimensions | 2,000 × 510 mm |
| Maximum table load | 1,000 kg |
| Spindle taper | BT40 / ISO40 |
| Spindle speed | 40 – 7,000 rpm |
| Main motor | approx. 11 kW |
| Tool magazine | 2 × 24 = 48 tools |
| Max. tool length | 350 mm |
| Max. tool weight | 8 kg |
| Max Tool Diameter | Ø 80 mm (110 mm if adjacent position is empty) |
| Rapid traverse X/Y | 24 m/min |
| Rapid traverse Z | 20 m/min |
| Machine weight | 7,320 kg |
