2006 COMU CLV 1100

2006 COMU CLV 1100



Machine is still under power and can be seen in production.

Currently there is a small defect that occasionally causes the tool changer to lock up and the spindle to stop. The machine can be put back into operation manually, but it would be advisable to replace/repair the switch arm brake motor.

In case of serial work without tool changes, the machine works perfectly.

The machine is immediately available.

Standard equipment:Frame in stabilized and cast mehanitic cast steelOversized prismatic guideways - hardened and ground (axes X - Y -Z)Counterconductions in TurciteGround and pre-tensioned ball screws diam 40 mm on the 3 axes - accuracy class C3Digital power enginesOrientable control panelAutomatic and timed lubrication on the 3 axesMain spindle cooling system with cooling group and temperature controlExternal cooling device with cooling water or compressed airOriented stop of the spindle - rigid tappingrinsing the chipsremovable chip traytightening bolts for clamping the tools (20 pieces) telescopic protections for the guideways (steel)integral protection - cabinet type with 2 frontal and 2 side doorscooling device for the electrical cabinetpneumatic cleaning of the spindle cone lighting at low voltageelectronic handwheelinstruction and programming manual (in Dutch language) accuracy protocolCE certificateCooling device through the center of the spindle (10 bar) with filter and chain chip conveyorDialog control « MANUAL GUIDE >>Color screen 8.4"Ethernet connection DATA server


ModelCLV 1100
Table surface1300 x 600 mm
X travel1100 mm
Y travel650 mm
Z travel600 mm
Work feed X-Y-Z1-8000 mm/min
Height of the table900 mm
ControlFANUC Oi-MC
Max allowed weight800 kg
Minimum distance between spindle nose and table140 mm
Maximum distance from spindle nose to table740 mm
Distance from spindle axis to upright700 mm
Spindle taperBT 40
Spindle diameter75 mm
Max spindle speed10000 rpm
Compressed air connection6 bar
Total installed power25 kW
Number of tools24
Max weight per tool6 kg
Length3000 mm
Depth3100 mm
Height3100 mm
Weight8000 kg
